F3 AIO 8/4 01 4 Start-Up
HI 800 161 E Rev. 1.01 Page 31 of 54
4.1.1.1 Shunt Adapter
The shunt adapter is a plug-in module for the analog inputs of the safety-related remote I/O
F3 AIO 8/4 01.
Five variants are available:
Model Equipment Part no.
Z 7301
250 Ω shunt
98 2220059
Z 7302
500 Ω shunt
98 2220067
Z 7306
250 Ω shunt
Overvoltage protection
HART series resistor (current limiting)
98 2220115
Z 7308
Voltage divider
Overvoltage protection
98 2220137
Z 7309
1)
500 Ω shunt
98 2220177
1)
If proximity switches are connected, see Chapter 4.5.1
Table 24: Shunt Adapter
Refer to the corresponding manuals for further information on the shunt adapters.
4.1.2 Connecting the Analog Outputs
Use the following terminals to connect the analog outputs:
Terminal Designation Function (analog outputs AO)
25 1+ Analog output 1
26 1- Ground output 1
27 2+ Analog output 2
28 2- Ground output 2
29 3+ Analog output 3
30 3- Ground output 3
31 4+ Analog output 4
32 4- Ground output 4
Table 25: Terminal Assignment for the Analog Outputs
