4.3.2 Analog Inputs F3 AIO 8/4 01
The following tables present the statuses and parameters for the input module (AI 8) in the
same order as given in the Hardware Editor.
4.3.2.1 Module Tab
The Module tab contains the following system parameters.
System parameter Data type R/W Description
AI.Error Code WORD R Error codes for all analog inputs
Coding Description
0x0001 Fault within the digital inputs
0x0002 FTT test of test pattern faulty
Module.Error Code WORD R Module error code
Coding Description
0x0000
I/O processing, if required with
errors, see other error codes
0x0001
No I/O processing (CPU not in
RUN)
0x0002
No I/O processing during the
booting test
0x0004 Manufacturer interface operating
0x0010
No I/O processing: incorrect
configuration
0x0020
No I/O processing: fault rate
exceeded
0x0040/
0x0080
No I/O processing: configured
module not plugged in
Module.SRS UDINT R Slot number (System Rack Slot)
Module.Type UINT R Type of module, target value: 0x00A5 [165
dec
]
Transmitter Voltage[01] USINT W Switching of the transmitter supply for each group:
1 = 8.2 V
2 = 26.0 V
Transmitter.Error Code WORD R Error codes for the transmitter unit
Coding Description
0x0001 Fault in the transmitter supply
0x0400
FTT test 1: Temperature threshold
exceeded
0x0800
FTT test 2: Temperature threshold
exceeded
Transmitter[01].Error Code BYTE R Error codes for each transmitter group
Coding Description
0x01 Module fault of transmitter supply
0x02 Overcurrent of transmitter supply
0x04 Low voltage of transmitter supply.
0x08 Overvoltage of transmitter supply.
Table 26: SILworX - System Parameters for the Analog Inputs, Module Tab
