3 Product Description X-COM 01
Page 10 of 42 HI 801 011 E Rev. 5.00
3 Product Description
The X-COM 01 communication module is intended for use in the programmable electronic
system (PES) HIMax.
The module is inserted into any of the base plate slots with the exception of the slots reserved
for system bus modules. For more information, refer to the System Manual (HI 801 001 E).
The module is approved for use in the safety-related HIMax system and can be used to
transport safety-related protocols.
The module ensures communication with systems via Ethernet and fieldbus interfaces with
safeethernet and different standard protocols.
Fore more information on how to configure the protocols and for details of the fieldbus
interfaces, refer to the Communication Manual (HI 801 101 E).
Use the SILworX programming tool to select the interfaces for the available protocols.
3.1 Safety Function
No safety function is performed by the communication module.
3.1.1 Reaction in the Event of a Fault
If fault occur, the module enters the temporary ERROR STOP. The module is then rebooted
and restarted from the INIT state.
No process data is exchanged with external communication partners in the ERROR STOP
state. No process data is transferred to process module.
3.2 HIMax COM Module Part Number
Each COM module forms a functional unit with the X-CB 001 02 connector board. Note that the
connector board must be separately purchased.
The fieldbus submodules are optional and must be mounted by the manufacturer. The fieldbus
submodule is selected when ordering the controller using the part number. Additionally, the
protocols used must be activated.
Improper opening of the COM module
Damage to COM module
Only HIMA is authorized to retrofit the fieldbus submodules.
When the module is equipped with one or multiple fieldbus submodules, the part number and
also the module name changes from X-COM 01 to X-COM 010 XY.
