X-COM 01 3 Product Description
HI 801 011 E Rev. 5.00 Page 11 of 42
The following table specifies the available components:
Designation
Description
X-COM 01
Communication module without fieldbus submodules
X-COM 010 XY
1)
Communication module with fieldbus submodule
X-CB 001 02
Connector board
1)
X: Option for fieldbus interface FB1 according to Table 4
Y: Option for fieldbus interface FB2 according to Table 4
Table 3: Available HIMax Components
Numbers are allocated to the fieldbus to create the part numbers, see Table 4.
Options for
FB1(X) and FB2(Y)
Description
0
No fieldbus submodule inserted
1
RS485 for Modbus (master or slave) or ComUserTask
2
PROFIBUS DP master
3
PROFIBUS DP slave
5
RS232 for ComUserTask
6
RS422 for ComUserTask
7
SSI for ComUserTask
Table 4: Options for Fieldbus Interfaces FB1(X) and FB2(Y)
The following table shows examples for part numbers and names:
Part no.
Designation
Fieldbus submodule 1
(FB1)
Fieldbus submodule 2 (FB2)
98 5260021
X-COM 010 21
PROFIBUS master
(max. 12 Mbit/s)
RS485
98 5260023
X-COM 010 23
PROFIBUS master
(max. 12 Mbit/s)
PROFIBUS slave
(max. 1.5 Mbit/s)
98 5260011
X-COM 010 11
RS485
RS485
98 5260000
X-COM 01
---
---
Table 5: Examples of COM Module Part Numbers and Names
i
HIMA recommends operating the PROFIBUS DP using the FB1 fieldbus interface (maximum
transfer rate 12 Mbit/s). The maximum transfer rate permitted for the FB2 fieldbus interface is
1.5 Mbit/s.
The designation and part number (part no.) are printed on the type label of the module.
For more information, refer to the SILworX Communication Manual (HI 801 101 E).
