Mirroring
Mirroring is used to configure whether the module should duplicate Ethernet packets on a given
port such that they can be read from a device connected to that port, e.g., for test purposes.
The following parameters define how a given port should work:
Off
This port does not participate to the mirroring process.
Egress:
Outgoing data of this port are duplicated.
Ingress/Egress:
Incoming and outgoing data of this port are duplicated.
Dest Port:
This port is used to send duplicated data.
Default setting: OFF
4.3.2 Network Ports Used for Ethernet Communication
UDP Ports / Use
123
SNTP (time synchronization between PES and remote I/O, PES and external
devices)
502
Modbus salve (can be modified by the user)
6010
safeethernet and OPC
8001
PES used to configure the remote I/Os
8000
Programming and operation with SILworX
34964
PROFINET endpoint mapper (required for establishing the connection)
49152
PROFINET RPC server
49153
PROFINET RPC client
TCP Ports / Use
502
Modbus salve (can be modified by the user)
Xxx
TCP SR assigned by the user
i
All ports listed above are destination ports. The source ports of the communication modules are
variable and cannot be affected.
The ComUserTask can use any port if it is not already used by another protocol.
