HIMA Himax X-COM 01 User Manual

3 Product Description X-COM 01
Page 18 of 42 HI 801 011 E Rev. 5.00
3.4.7 Fieldbus Indicators
The fieldbus LEDs are labeled Fieldbus.
LED
Color
Status
Description
1, 2
Yellow
On
Fieldbus operating
Off
No activity, fieldbus not operating
Fault
Red
Blinking1
Fieldbus fault of the bus (e.g., the slave is not present
or faulty response), depending on the fieldbus protocol
(minimum blinking duration 5 s).
Off
No fieldbus faults
Table 12: Fieldbus Indicators
3.4.8 Ethernet Indicators
The Ethernet LEDs are labeled Ethernet.
LED
Color
Status
Description
Eth 1…4
Green
On
Communication partner connected
No communication detected on interface
Blinking-x
Communication detected on interface.
Blinking1
IP address conflict detected
All Ethernet LEDs are blinking
Off
No communication partner connected
H/F/Col
1…4
Yellow
On
Full duplex operation on Ethernet line F
Blinking-x
Collisions detected on Ethernet line Col
Blinking1
IP address conflict detected
All Ethernet LEDs are blinking
Off
Half duplex operation on Ethernet line H
Table 13: Ethernet Indicators
