5 Operation X-COM 01
Page 32 of 42 HI 801 011 E Rev. 5.00
5 Operation
The module runs within a HIMax base plate and does not require any specific monitoring.
5.1 Handling
Direct handling of the module is not foreseen.
The module is operated from within the PADT. For more details, refer to the SILworX
documentation.
5.2 Diagnosis
LEDs on the front side of the module indicate the module state, see Chapter 3.4.3.
The diagnostic history of the module can also be read using SILworX.
i
If a module is plugged in to a base plate, it generates diagnostic messages during its
initialization phase indicating faults such as incorrect voltage values.
These messages only indicate a module fault if they occur after the system starts operation.
