HIMA Himax X-COM 01 User Manual

4 Start-up X-COM 01
Page 24 of 42 HI 801 011 E Rev. 5.00
4.2.2 Mounting and Removing the Module
This chapter describes how to mount and remove the HIMax module. A module can be mounted
and removed while the HIMax system is operating.
NOTE
Damage to bus and power sockets due to module jamming!
Failure to observe this can damage the controller.
Always take care when inserting the module in the base plate.
Tools and utilities
 Screwdriver, slotted 0.8 x 4.0 mm
 Screwdriver, slotted 1.2 x 8.0 mm
Installation
1. Open the cover plate on the fan rack:
 Move the locks to the open position.
 Lift the cover plate and insert into the fan rack
2. Insert the top of the module into the hook-in rail, see .
3. Swivel the lower edge of the module towards the base plate and apply light pressure to snap
it into place, see .
4. Tighten the screws, see .
5. Pull the cover plate out of the fan rack and close it.
6. Lock the cover plate.
Removal
1. Open the cover plate on the fan rack:
 Move the locks to the open position.
 Lift the cover plate and insert into the fan rack
2. Release the screw .
3. Swivel the lower edge of the module away from the base plate. Lift and apply light pressure
to remove the module from the hook-in rail, see and .
4. Pull the cover plate out of the fan rack and close it.
5. Lock the cover plate.
