HIMA Himax X-COM 01 User Manual

3 Product Description X-COM 01
Page 14 of 42 HI 801 011 E Rev. 5.00
3.4.2 Processor System
The processor system uses self tests to control and monitor the communication. Data is
exchanged between the communication module and the processor module is carried out via
redundant system bus. The system bus has a redundant structure for reasons of availability.
Redundancy is only ensured if both system bus modules are inserted in the base plates and
configured accordingly.
Operating system and error code history are stored in a non-volatile memory and can be read in
SILworX via the diagnosis.
Ethernet Switch
Integrated Ethernet switch to configure different networks.
Ethernet interface
The communication module is equipped with four Ethernet switch ports connected to the
Ethernet interface of the processor system via an integrated Ethernet switch.
Property
HIMax COM module
Ports
4
Transfer standard
10BASE-T/100BASE-Tx,
Half and full duplex
Auto negotiation
Yes
Auto crossover
Yes
Connection Socket
RJ-45
IP address
Freely configurable
1)
Subnet mask
Freely configurable
1)
Supported protocols
safeethernet
Standard Protocols
1)
The general rules for assigning IP address and subnet masks must be adhered to.
Table 6: Ethernet Interface Properties
i
Ensure that no loops result from the network wiring. Data packets may only reach a controller
over a single path.
Fieldbus Interfaces
The fieldbus submodules activate the fieldbus interfaces and define the interface transfer
standard. The required fieldbus submodules must be specified when ordering the module, see
Chapter 3.2. Only one protocol can be run on each fieldbus interface.
Fieldbus interfaces
Number
2
Transfer standard
For each fieldbus submodule
Connection Socket
D-sub connector, 9 poles
Supported protocols
Standard protocols, see Communication
Manual (HI 801 101 E).
Table 7: Fieldbus Interface Specifications
i
Wiring, Bus Termination:
 Observe the corresponding fieldbus standard when connecting the fieldbus interfaces.
 Use the bus terminations to terminate the fieldbuses on their physical ends.
