27
___________________________________________________________________
Chapter 5 Advanced Measurement Functions
___________________________________________________________________
Voltage range
(5) Setting the voltage range
1. Using the key, move the flashing number to the least
significant digit of the upper resistance limit setting at the
lower right of the screen.
2. Press the
key again to display the voltage comparison
value setting screen will appear.
"
COMP.SET
"and"
VOLT
" appear while setting the voltage
comparison value.
3. Press the voltage range key (
VRANGE
:
3
,
30
)
corresponding to the voltage to be measured.
The position of the decimal point corresponds to the
currently selected voltage range.
