Hioki 3550 - Moving Average Function

39
___________________________________________________________________
Chapter 5 Advanced Measurement Functions
___________________________________________________________________
5.5 Movin
g
Avera
g
e Function
If the resistance measurement value is unstable, this can be
corrected with the moving average function. This takes the
average of four samples of the resistance value and displays
the result.
The moving average takes the sum of the current value and
the previous three sampled values, and divides by four.
To take the moving average, use the following procedure.
1. Power the unit off.
2. Hold down the key while pressing the
POWER
key.
3. Hold down the
key until a screen for setting the moving
average appears.
4. Press the
key once more.
