4.13 Reset Function
72
The reset function can be used to re-initialize current measurement settings
(excluding saved panel data) to their factory defaults, or to re-initialize all mea-
surement settings including saved panel data to factory defaults.
4.13 Reset Function
1
(The SHIFT indicator lights up.)
The Menu display appears.
2
The Reset display appears.
See "1.4 Menu Display Sequence (SHIFT → ENTER)" (⇒ p.13).
3
Select the Reset method on the Sub Display.
SEt ........ Reset (initializes measurement settings other than those stored
with Panel Save)
SYS....... System Reset (initialize all measurement settings)
4
ENTER blinks.
5
Executes the Reset.
To cancel the settings:
SHIFT key
(Main Display)
(Sub Display)
The current setting blinks.
(Sub Display)
When SYS (system reset) is selected
System Reset also initializes Panel Save data.
