2
For the [Setting], click the [Logger] but-
ton.
The Logger Settings screen appears.
(If the logger is not connected, you are
prompted to connect it. Connect the logger.)
3
Select the logger from the device list*,
and edit the settings. (p.34)
4
Click the [Send Settings] button.
4
How can current settings be imported from the connected logger?
1. Click the [Import Settings] button at the upper right of screen.
(A dialog appears.)
2. Click the [Import Settings to Computer] button. (The logger's settings
are now reflected in the program.)
2
Click to select.
The currently selected logger's back-
ground is a different color.
3
Setting Options
Note: The displayed settings are those previously made
from the LR5000 Utility Program, which may be differ-
ent from the current settings within the logger itself.
* About the Device List
• Up to ten loggers can be displayed when connected to the computer.
• When [Show disconnected loggers] is selected, disconnected loggers that had set-
tings previously saved appear in the list.
• The list can be sorted in ascending order ([Sort List]).
Returns to the
main screen.
Settings from other loggers can
be applied. (p.34)
To Next Page
