The main screen appears automatically.
If newly recorded data exists, the import confirmation dialog appears.
If the data import screen is displayed before connecting the logger, the import confirma-
tion dialog does not appear. Import manually. (p.55)
3
Click [Yes].
The viewer opens to display the
graph (Auto Graph Display).
Note: By default, [Automatically dis-
play graph when data is
imported] (on the Options
screen) is enabled. (p.78)
The data recorded in the logger is
imported to the computer automati-
cally.
Imported data is saved to a file
(Auto Import).
Note: By default, [Automatically
import and store data when
the logger is connected to a
computer] (on the Options
screen) is enabled. (p.78)
How is recorded data saved?
Recorded data is automatically saved when imported to a computer.
The save destination and file name are specified as a basic setting on the
Options screen.
3
To Next Page
