8.4 LR5091 Communication Adapter Specifications
86
Data import functions
• Communicates with the LR5000-series loggers, and imports recorded
data
• Combines recorded data
• Incorporates new data when an LR5000-serie
s logger holds data not
previously imported
(the following functions are supported by the supplied PC Utility version
2.
00, or later)
• Communicates with the LR5092-20 Data Collector, and imports
re
corded data saved in the Data Collector
• Imports data saved to an SD memory card in the LR5092-20 Data Collec-
tor
Graph display functions
• Displays up to 16 channels in a graph
• Displays up to 16 Y-axes
• Displays one time base axis
• Set line colors for each channel, and display/hide lines and bar graphs
fo
r each channel
• Auto setting of time base and vertical axis
• Display/hide Y-axis grid lines, and set grid display density
• Select display background color
• Copy graph images to the clipboard
• A/B cursor functions
• Displays statistical data (maximum, minimum, and average)
Data list display functions
• Browse recorded data in tabular format
• Displays up to 600 channels
• Displays statistical data (maximum, minimum, and average)
Export functions
• Export all recorded data displayed in a table in CSV format
• Paste to Excel all recorded data displayed in a data table
• Export all recorded data between A/B cursors in CSV format
• Paste to Excel all recorded data between A/B cursors
Import functions
Import text files from the 3169 Clamp-On Power HiTester
Note: Only electric energy data recorded at one
-second or longer inter-
val can be imported
Printing functions
• Prints graphs and statistical data
• Supports A3, A4, and B4 paper sizes
Data processing
functions
Scaling (y=a×x+b), electric power calculation, energy cost calculation,
operating rate calculation, integration, dew-point temperature calcula-
tion, arithmetic calculations, out-of-range data revision
File management
functions
• Copy and delete data saved on the computer
(the following functions are supported by the supplied PC Utility version
2.
00, or later)
• Delete data saved to an SD memory card in the LR5092-20 Data Col-
lector
Help function Displays helpful operating instructions
