SPN Definition
The SPN are divided into three types: nummerical, status and string.
Parameter Nummerical SPN
byteSize Size of the data in bytes.
offset The offset in the can-data.
formatGain The numerical factor used to give the value.
formatOffset The numerical offset of the value.
units The physical unit of the value.
name Name of the SPN.
number The SPN number.
type 0 -> Nummerical SPN.
Parameter Status SPN
bitSize Size of the data in bits.
bitOffset The offset in bits in the byte.
offset The offset in bytes.
descriptions Array containing the status description.
name Name of the SPN.
number The SPN number.
type 1 -> Status SPN.
Parameter String SPN
name Name of the SPN.
number The SPN number.
type 2 -> String SPN.
