Service Manual iFLEX5
© Hirschmann Rev. I 0522/17 190154_I.DOC
30
*adctest
T E S T D E R A N A L O G E I N G A E N G E
===============================================
Ch | MUX | Error | Kanal+ | Value | Value | UADC | Special
| | | Valid | (Hex) | (Dec) | [mV] |
---+-----+-------+--------+-------+-------+------+-----------------
0 | | ok | 0008 | 0310 | 784 | 784 | I_Kanal 1 = 4.356 mA
1 | | ok | 0009 | 0816 | 2070 | 2070 | I_Kanal 2 = 11.500 mA
2 | | ok | 000A | 0000 | 0 | 0 | I_Kanal 3 = 0.000 mA
3 | | ok | 000B | 0000 | 0 | 0 | I_Kanal 4 = 0.000 mA
4 | | ok | 000C | 0307 | 775 | 775 | Temperature = +27°C
5 | 0 | ok | 000D | 0B90 | 2960 | 2960 | I_Kanal 5 = 16.444 mA
5 | 1 | ok | 000D | 0000 | 0 | 0 | I_Kanal 6 = 0.000 mA
5 | 2 | ok | 000D | 0000 | 0 | 0 | I_Kanal 7 = 0.000 mA
5 | 3 | ok | 000D | 0000 | 0 | 0 | I_Kanal 8 = 0.000 mA
5 | 4 | ok | 000D | 0098 | 152 | 152 | I_PWM 1 = 0 mA
5 | 5 | ok | 000D | 0014 | 20 | 20 | I_PWM 2 = 10 mA
5 | 6 | ok | 000D | 0000 | 0 | 0 | I_PWM 3 = 0 mA
5 | 7 | ok | 000D | 0000 | 0 | 0 | I_PWM 4 = 0 mA
OPERATINGMODE
X: Exit Blank: Redraw S: Slow F: Fast P: PWM-Settings
T: Test mode O: Operating mode C: ADC-Clock set E: Extension module T
E S T D E R A N A L O G E I N G A E N G E
Kanal
Description
1
Slew Angle 1
2
Slew Angle 2
3
Wind Speed
5
Luffing Extension Offset Angle
PWM
Description
1
Center-Mid Tele Output
2
Inner-Mid Tele Output
3
Luffing Extension Raise Output
4
Luffing Extension Raise Output
Note: DO 1 = PWM 1
DO 3 = PWM 2
DO 5 = PWM 3
DO 7 = PWM 4
