iFLEX5 Boom Control System (BCS)
© Hirschmann Rev. I 05/22/17 190154_I.DOC
31
Boom Status /
Luffer Status
IM Tele Output
(0-255)
CM Tele Output
(0-255)
Luffing Ext
Raise Output
(0-255)
Luffing Offset
Angle(degrees)
Length 2 (IM)
(feet)
14.6 IFLEX5 BCS TEST DISPLAY:
To view additional information on the console display, push buttons “F1” and “F4”
simultaneously. To return to the normal screen push button “F1” or “F4”.
Status No.
Description
1 - 11
Mode B extend
29
Error Mode B extend
31 - 41
Mode B retract
59
Error Mode B retract
61 - 67
Mode A extend
79
Error Mode A extend
81 - 85
Mode A retract
99
Error Mode A retract
100
Manual Mode A neutral or extend
101
Manual Mode B neutral or extend
102 - 108
Manual Mode retract at overload, A2B, error condition
110
Mode A, Out of Sequence
112
Mode B, Out of Sequence
127
Mode A or B, neutral position
200 - 202
Luffing jib raise
210 - 212
Luffing jib lower
