Assistance in the Protection from Un-
authorized Access
UM Basic Configuration L3P
Release
7.1
12/2011
6.8
Access Control Lists (ACL)
115
ACL ID: 100
Rule Number: 1
Action......................................... deny
Match All...................................... FALSE
Protocol....................................... 255(ip)
Source IP Address.............................. 10.0.1.11
Source IP Mask................................. 0.0.0.0
Destination IP Address......................... 10.0.1.158
Destination IP Mask............................ 0.0.0.0
Rule Number: 2
Action......................................... permit
Match All...................................... TRUE
configure Switch to the Configuration mode.
interface 2/3 Switch to the Interface Configuration mode of
interface 2.3.
ip access-group 100 in Attaches ACL 100 to interface 2.3 for received
data.
exit Switch to the Configuration mode.
interface 3/1 Switch to the interface configuration mode of
interface 3.1.
ip access-group 110 in Attaches ACL 110 to interface 3.1 for received
data.
exit Switch to the Configuration mode.
exit Switch to the privileged EXEC mode.
show access-lists interface 2/3 in
ACL Type ACL ID Sequence Number
-------- ------------------------------- ---------------
IP 100 1
