Access to the user interfaces
16
1.1
System Monitor
UM Basic Configuration L3P
Release
7.1
12/2011
1.1 System Monitor
The system monitor enables you to
select the software to be loaded
perform a software update
start the selected software
shut down the system monitor
delete the configuration saved and
display the boot code information.
Opening the system monitor
Use the terminal cable (see accessories) to connect
– the V.24 socket (RJ11) to
– a terminal or a COM port of a PC with terminal emulation based on
VT100
(for the physical connection, see the "Installation" user manual).
Start the terminal program on the PC and set up a connection with the
device.
When you boot the device, the message
"Press <1> to enter System Monitor 1"
appears on the terminal.
Speed 9,600 Baud
Data 8 bit
Parity None
Stopbit 1 bit
Handshake Off
Table 1: Data transfer parameters
