EtherNet/IP
UM Basic Configuration L3P
Release
7.1
12/2011
10.2
EtherNet/IP Parameters
261
10.2.4 Ethernet Switch Agent Object
The switch supports the Hirschmann vendor specific Ethernet Switch Agent
Object (Class Code 95
H,
149) for the switch configuration and information
parameters with one instance (Instance 1).
For further information on these parameters and how to adjust them refer to
the Reference Manual „GUI“ (Graphical User Interface / Web-based
Interface).
Attribute ID/Bit No. Description
Switch Status ID 01 DWORD (32 bit) RO
Bit 0 Overall state (0: ok, 1: failed) Like the signal contact.
Bit 1 Power Supply 1 (0: ok, 1: failed or does not exist)
Bit 2 Power Supply 2 (0: ok, 1: failed or does not exist)
Bit 3 Power Supply 3 (0: ok or not possible on this platform, 1: failed
or does not exist)
Bit 4 Power Supply 4 (0: ok or not possible on this platform, 1: failed
or does not exist)
Bit 5 Power Supply 5 (0: ok or not possible on this platform, 1: failed
or does not exist)
Bit 6 Power Supply 6 (0: ok or not possible on this platform, 1: failed
or does not exist)
Bit 7 Power Supply 7 (0: ok or not possible on this platform,
1: failed or does not exist)
Bit 8 Power Supply 8 (0: ok or not possible on this platform,
1: failed or does not exist)
Bit 9 DIP RM (ON: 1, OFF: 0)
Bit 10 DIP Standby (ON: 1, OFF: 0)
Bit 11 Signal Contact 1 (0: closed, 1: open)
Bit 12 Signal Contact 2 (0: closed, 1: open)
Bit 16 Temperature (0: ok, 1: threshold exceeded)
Bit 17 Fan (0: ok or no fan, 1: inoperable)
Bit 21 DIP Ring ports, 0: module 1 ports 1&2, 1: module 2, ports 1&2
Bit 22 DIP Configuration (1: enabled, 0: disabled)
Bit 23 DIP HIPER-Ring state (1: ON, 0: OFF)
Bit 24 Module removed (1: removed)
Bit 25 ACA removed (1: removed)
Bit 28 Hiper-Ring (1: loss of redundancy reserve)
Bit 29 Ring-/Netcoupling (1: loss of redundancy reserve)
Bit 30 Connection Error (1: link inoperable)
Table 36: Hirschmann Ethernet switch Agent Object
