EtherNet/IP
260
10.2 EtherNet/IP Parameters
UM Basic Configuration L3P
Release 7.1 12/2011
The switch supports additional vendor specific attributes.
Id Attribute Access
rule
Data type Description
100
(64
H)
Ethernet
Interface Index
Get UDINT Interface/Port Index (ifIndex from MIB II)
101
(65
H)
Port Control Get/Set DWORD Bit 0 (RO): Link state (0: link down, 1: link up)
Bit 1 (R/W): Link admin state (0: disabled,
1: enabled)
Bit 8 (RO:) Access violation alarm
Bit 9 (RO): Utilization alarm
102
(66
H)
Interface
Utilization
Get UDINT The existing Counter from the private MIB
hmIfaceUtilization is used. Utilization in
percentage
a
. RX Interface Utilization.
a. Unit: 1 hundredth of 1%, i.e., 100 corresponds to 1%
103
(67
H)
Interface
Utilization
Alarm Upper
Threshold
Get/Set UDINT Within this parameter the variable
hmIfaceUtilizationAlarmUpperThreshold can
be accessed.
Utilization in percentage
a
. RX Interface
Utilization Upper Limit.
104
(68
H)
Interface
Utilization
Alarm Lower
Threshold
Get/Set UDINT Within this parameter the variable
hmIfaceUtilizationAlarmLowerThreshold can
be accessed.
Utilization in percentage
a
. RX Interface
Utilization Lower Limit.
105
(69
H)
Broadcast Limit Get/Set UDINT Broadcast limiter Service (Egress BC-Frames
limitation, 0: disabled), Frames/second
106
(6A
H)
Ethernet
Interface
Description
Get STRING
[max. 64 Bytes]
even number of
Bytes
Interface/Port Description
(from MIB II ifDescr), e.g. "Unit: 1 Slot: 2 Port:
1 - 10/100 Mbit TX", or "unavailable",
max. 64 Bytes.
Table 35: Hirschmann Ethernet Link Object Extensions
