Hirschmann PowerMICE User Manual

EtherNet/IP
UM Basic Configuration L3P
Release 7.1 12/2011
10.2 EtherNet/IP Parameters
265
Id Attribute Access
rule
Data type Description
1 Bridge Identifier
Priority
Set UDINT Range: 0 to 61,440 in steps of 4,096, default:
32,768
(refer to IEEE, 802.1D-2004, § 17.13.7)
2 Transmit Hold
Count
Set UINT Range: 1 to 40, default: 10
(refer to IEEE 802.1D-2004, §17.13.12)
3 Force Protocol
Version
Set UINT Default:2
(refer to IEEE 802.1D-2004, §17.13.4 and
dot1dStpVersion in RFC 4318)
4 Bridge Hello Time Set UDINT Range: 100 to 200, unit: centi-seconds (1/100 of
a second), default: 200
(refer to IEEE 802.1D-2004, §17.13.6 and
dot1dStpHoldTime in RFC 4188)
5 Bridge Forward
Delay
Set UDINT Range: 400 to 3000, unit: centi-seconds, default:
2100
(refer to IEEE 802.1D-2004, §17.13.5 and
dot1dStpForwardDelay in RFC 4188)
6 Bridge Max. Age Set UINT Range: 600 to 4000, unit: centi-seconds, default:
4000
(refer to IEEE 802.1D-2004, §17.13.8 and
dot1dStpBridgeMaxAge in RFC 4188)
7 Time Since
Topology Change
Get UDINT Unit: centi-seconds
(refer to dot1dStpTimeSinceTopologyChange in
RFC 4188)
8 Topology Change Get UDINT Refer to dot1dStpTopChanges in RFC 4188
100 InnerPort Get UINT Hirschmann-specific object.
 For instance 1, it holds the port number of the
DRSTP Primary instance‘s inner port.
 For instance 2, it holds the port number of the
DRSTP Secondary instance‘s inner port.
101 OuterPort Get UINT Hirschmann-specific object.
 For instance 1, it holds the port number of the
DRSTP Primary instance‘s outer port.
 For instance 2, it holds the port number of the
DRSTP Secondary instance‘s outer port.
Table 37: Hirschmann RSTP Bridge Object
