Hirschmann qSCALE i2 - Boom Height Monitoring

Operation
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 27/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
3.3.3 Boom Height Monitoring
Boom Height Limit is able to be programmed.


MAIN
WORKING
SCREEN
USER
LIMITS
BOOM
HEIGHT
LIMIT
Set and Save Current Tip Height as Height Limit
Activate or Deactivate Height Limit
Deactivate Limits
Example
Function Keys
Current Height
Saved Height Limit
