Hirschmann qSCALE i2 - Extended Information Menu

Service and Maintenance
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 39/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
4.3.2 Extended Information Menu
In this menu different information can be displayed about the defined sensors.



MAIN
WORKING
SCREEN
OP-MODE
CONFIRM
INFORMATION
SELECTION
EXTENDED
INFORMATION
Console I/O
(see Service Manual)
CAN Sensor Information
(see Service Manual)
DIO I/O
(see Service Manual)
Function Keys
