1 Safety Instructions
WARNING
Imminent threat of personal injury and damage to property due to incorrect system settings!
The correct adjustment of the Rated Capacity Limiter (RCL) to the current set-up status is
essential for the correct function of the system and of the machine.
The RCL can only operate correctly if all settings are entered correctly according to the
current set-up status during the SETUP procedure.
The settings can only be carried out by operators who are completely familiar with the oper-
ation and functions of the machine and the RCL.
The correctness of these settings must be guaranteed before starting the machine opera-
tions!
CAUTION
The user limit function is a monitoring function.
Crane movements are not switched off when user limit values are reached or exceeded!
If one or more limits are reached or exceeded, the background color of the LIM key changes
to yellow. The corresponding values are also displayed in yellow. The audible alarm will not
activate!
IMPORTANT
Connection to the wrong power supply will cause damage to the device.
The device may only be connected to a DC voltage source of 10 V to 30 V!
1.1 EC conformity declaration
The technical design and construction of the qSCALE i2 system corresponds to requirements of
the EMC directive 2004/108/EC and therefore carries the CE symbol.
The device complies with the following standards:
EN 12895:200, EN 13309:2010, EN ISO 14982: 2009
The full conformity declaration is available from the manufacturer on request.
