Hirschmann qSCALE i2 User Manual

Service and Maintenance
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 29/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
4 Service and Maintenance
Information provided in the Operators Manual is for reference. For more information please refer to
the Service Manual. The service screens are accessed through the Op-Mode Confirm screen.

MAIN
WORKING
SCREEN
OP-MODE
CONFIRM
Setup
(see Section 4.2)
Operation Mode Selection
(see Section 2.2.1)
Information Selection
(see Section 4.3)
Select Reeving
(see Section 2.2.3)
System Event Information
(see Section 3.2)
NOTE
Many setup menus are password-protected. They are marked as follows:
Password protected Setup password required
Password protected Administrator password required
See Section 4.1 for password entry information
