Service and Maintenance
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 32/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
4.2.1 Brightness & Volume
In this menu settings can be made to the buzzer volume and brightness of display and illumination.



MAIN
WORKING
SCREEN
OP-
MODE
CONFIRM
SETUP
SETUP
DISPLAY
LCD Brightness
Beeper Volume
Key Brightness
All three settings can be set by the following instructions:
 Turn the rotary encoder to clockwise to increase value
 Turn the rotary encoder counter clockwise to decrease value
 Once the desired brightness is selected, press the SET function key to set.
 To abort, press the ESCAPE function key
Function
Keys
Instructions
