4.3.1 Sensor Information Menu
In this menu different information can be displayed about the defined input sensors on the crane.



MAIN
WORKING
SCREEN
OP-MODE
CONFIRM
INFORMATION
SELECTION
SENSOR
INFORMATION
Digital Input Information
(see Service Manual)
Analog Input Information
(see Service Manual)
Digital Output Information
(see Service Manual)
Analog Output Information
(see Service Manual)
NOTE
Available screens will vary depending upon system configuration!
Function Keys
