4.3 Information Selection Menu
The Information Selection Menu allows the user to view crane, sensor, and software version infor-
mation and is the starting point for diagnostic information.


MAIN
WORKING
SCREEN
OP-MODE
CONFIRM
INFORMATION
SELECTION
Sensor Information Screen
(see Section 4.3.1)
Crane Information
(see Section 4.3.1)
Information Selection (extended)
(see Section 4.3.2)
Version-Info
(see Section 4.3.4)
Function Keys
