Hirschmann qSCALE i2 User Manual

Appendix
© 2016 Hirschmann Automation and Control GmbH · Mobile Machine Control Solutions · www.beldensolutions.com 49/57
qSCALE i2 Cranes (Tool Version 3.0.34) Operators Manual / Issue B / 11-2017 / ac.
General Error Codes
Error
Code
Description
Error
Code
Description
0001
System started
0A12
Allowable load is reduced
0002
System restarted
0A13
Allowable load is reduced
0011
Output system version
0A14
Allowable load is reduced
0021
Output machine information
0A15
Allowable load is reduced
0070
Cyclic Logger Update
0A16
Allowable load is reduced
0071
Overload Logger Update
0A17
Allowable load is reduced
0072
Invalid operating mode Logger update
0A1F
Load on hook without Operating Mode
0073
Cyclic Logger Update
0A20
Shutdown due to overload
0081
Date set by user
0A21
Overload Warning
0082
Time set by user
0A22
Safety Cut
0090
Operating mode changed
0A23
Speed reduction
00AA
Output debug information
0A24
A2B switch
00FC
Controller Not Initialized
0A25
End of rope sensor
00FD
System Sleep Mode
0A26
High voltage detection
00FE
System restarted after deleting the application
0A27
Shutdown due to overload feedback monitoring
00FF
System stopped
0A28
Overload Warning feedback monitoring
1F00
System Error
0A29
Safety cut feedback monitoring
1F01
Timeout
0A2A
Speed reduction feedback monitoring
1F02
Timeout
0A2B
A2B switch feedback monitoring
1F03
Timeout
0A2C
End of rope sensor feedback monitoring
1F04
Timeout
0A2D
High voltage detection feedback monitoring
1F05
Timeout
0A2E
Summary cut
1F06
Timeout
0A2F
Summary cut feedback monitoring
1F07
Timeout
0A30
Setup mode 110%
1F08
Timeout
0A31
Rigging mode
1F10
Computer operation error
0A32
System Bypass
1F11
Computer operation error
0A33
System Bypass
1F12
Computer operation error
0A34
Boom up Switch
1F13
Computer operation error
0A35
Bypass A2B switch
1F14
Computer operation error
0A36
Bypass end of rope sensor
1F15
Computer operation error
0A37
System Bypass
1F16
Computer operation error
0A38
Bypass high voltage detection
1F17
Wrong data
0A39
Bypass end of outrigger cut
1F18
Serial Number wrong or not set
0A3C
Jib up motion disabled
1F1F
Outputs deactivated
0A3D
Jib up motion monitoring
1F2F
Outputs deactivated
0A3E
Jib down motion disabled
1F30
Redundancy error
0A3F
Jib down motion monitoring
1F31
Redundancy error
0A40
Boom up movement disabled
1F32
Redundancy error
0A41
Boom up movement monitoring
1F3F
Version Error
0A42
Boom down disabled
1F40
Power supply
0A43
Boom down movement monitoring
1F41
Battery voltage
0A44
Motion out disabled
1F42
Warning temperature
0A45
Motion out motion monitoring
1F43
Warning temperature
0A46
Motion in disabled
1F44
CAN bus network error
0A47
Motion in motion monitoring
1F4F
Version Error
0A48
Motion left disabled
1FFF
Fatal safety error
0A49
Motion left motion monitoring
2000
Module Error
0A4A
Motion right disabled
2001
Module Error
0A4B
Motion right motion monitoring
2002
Module Error
0A4C
Motion load up deactivated
2003
Module Error
0A4D
Motion load up motion monitoring
2004
Module Error
0A4E
Motion load down deactivated
2005
Module Error
0A4F
Motion load down motion monitoring
2010
Module Error
0A50
Invalid operation mode
2011
Module Error
0A51
Invalid telescope mode
2014
Module Error
0A52
Invalid reeving
2015
Module Error
0A53
Invalid winch configuration
