Remove
the
cassette
lid
and
top
cover.
(See
Figs.
2-2-1,
2-2-2)
(14)
Release
2
tabs
and
pull
out
the
loading
motor
from
the
loading
motor
holder.
(See
Fig.
3-3)
Note:
The
above
removal
is
different
from
normal
removal.
In
normal
circumstances,
remove
the
loading
motor
assembled
with
the
loading
motor
holder.
(The
loading
motor
and
loading
motor
holder
comprise
an
assembly.)
(15) Turn over the mechanism. (See Fig. 3-3)
Note:
Do
not
turn
over
with
the
idler
cover
removed.
(16)
Use
a
flat-bladed
screwdriver,
etc.
to
turn
cam
gear
(A)
or
(B).
(See
Fig.
3-3)
Turning
it
in
the
direction
of
the
arrow
will
unload
the
mechanism,
and
turning
it
in
the
opposite
direction
to
the
arrow
will
load
the
mechanism.
Notes:
¢
Be
careful
not
to
damage
the
cam
gears.
*
To
unload
the
mechanism
with
a
tape
inserted,
manually
turn
the
capstan
motor
simultaneously
to
take
up
the
tape.
A: Loading Motor
B: Loading Motor Holder
C: Cam Gear (A)
D: Cam Gear (B)
Fig. 3-3
E2-12
