Hitachi SU8700 - Protection against Movement Caused by Earthquake (Option); Main Unit

Protection against movement caused by earthquake (Option)
SAFETY-31
SAFETY SUMMARY
Protection against movement caused by earthquake (Option)
Main unit
* The values on this specification is based on the calculation.
Protection against movement caused by earthquake (Main unit) (Recommend)
Hexagon head bolt to floor
(M12
X 40 (or higher) SUS)
(4 pcs
)
Fore hexagon head bolts
mounting positions
Bottom view
