地震防范措施（选件）

安全-30

安全使用注意事项

地震防范措施（选件）

仪器本体

※ 本规格为依照计算得出的数值。

地震防范措施（仪器本体）（推荐例）

内六角螺栓

(

M12×40 mm 以上 SUS) (4 个)

内六角螺栓安装位置

下面图
