重量分配

安全-38

安全使用注意事项

重量分配（续）

EO 控制单元

※ 本规格为依照计算得出的数值。

EO 控制单元脚部的重量分配

约 66 kg

下面图

约 91 kg

约 60 kg

约 53 kg
