Hitachi WJ Series

Appendix
A-1-8
■ Three-phase 200 V 0.1 kW to 0.75 kW
WJ200-001LF/002LF/004LF/007LF
C1-001LF/002LF/004LF/007LF
■ Three-phase 200 V 1.5 kW to 2.2 kW, Three-phase 400 V 0.4 kW to 3.0 kW
WJ200-015LF/022LF
004HF/007HF/015HF/022HF/030HF
C1-015LF/022LF
004HF/007HF/015HF/022HF/030HF
Screw size
M3.5
Terminal block width
7.6 mm
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
RB
P/+
T/L3
S/L2
R/L1
N/-
Short-
circuit bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
RB
P/+
T/L3
S/L2
R/L1
N/-
Short-
circuit bar
Screw size
M3.5
Terminal block width
7.3 mm
Charge
lamp
Ground
terminal
M4×2
Charge
lamp
Ground bar M4×2
Charge
lamp
Ground
terminal
M4×2
Charge
lamp
Ground
bar
M4×2
Screw size
M4
Terminal block width
9.9 mm
Short-
circuit bar
Power supply input wire
Motor output
wire
W/T3
V/T2
U/T1
RB
P/+
T/L3
S/L2
R/L1
N/-
Screw size
M4
Terminal block width
10 mm
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
RB
P/+
T/L3
S/L2
R/L1
N/-
Short-
circuit bar
