Hitachi WJ Series - Page 478

Appendix
A-1-9
■ Three-phase 200 V 3.7 kW, Three-phase 400 V 4.0 kW
WJ200-037LF/040HF
C1-037LF/040HF
■ Three-phase 200 V 5.5 kW/7.5 kW, Three-phase 400 V 5.5 kW/7.5 kW
WJ200-055LF/075LF/055HF/075HF
C1-055LF/075LF/055HF/075HF
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
RB
P/+
T/L3
S/L2
R/L1
N/-
Short-
circuit bar
Screw size
M4
Terminal block width
10 mm
Screw size
M4
Terminal block width
9.9 mm
Short-
circuit bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
RB
P/+
T/L3
S/L2
R/L1
N/-
Screw size
M5
Terminal block width
13 mm
Ground
terminal
Short-
circuit
bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
P/+
T/L3
S/L2
R/L1
N/-
RB
G
G
Screw size
M5
Terminal block width
13 mm
Ground
terminal
Short-
circuit
bar
Power supply input wire
Motor output wire
W/T3
V/T2
U/T1
P/+
T/L3
S/L2
R/L1
N/-
RB
G
G
Charge
lamp
Ground
terminal
M4×2
Charge
lamp
M4×2
Charge
lamp
Charge
lamp
