10 11
Quick Start Guides
We recommend that you read the introductory information in section one, then proceed to one of the
quick start guides and start programming. After following along with the quick start guide you will have
a feel for the way the FLASH 8 programming is laid out. We encourage you to set up a few aircraft before
you y the FLASH 8. It will be time well spent and help acquaint you with the programming process.
Quick Start Guides
System Component Specifications
FLASH 8 Transmitter
Modulation: 2.4GHz
Optima (AFHSS Bidirectional): For use with the Optima series telemetry capable receivers.
Minima (AFHSS Single-direction): For use with the Minima series receivers.
Maxima (AFHSS Single-direction): For use with the High response low latency Maxima series receivers.
Power Supply: 2Cell Li-Fe Battery or Optional 4.8-7.2v NiMh or Li-Ion or Li-Po Battery
Current Drain: 300 mA
Available Receivers
Optima Series 2.4GHz Receivers
Model Size Weight Stock Number
Optima 6 Lite 1.76 x 1.11 x 0.29in (44.9 x 18.4 x 7.40mm) 0.33oz (9.4g) 29438
Optima 6 1.81 x 0.82 x 0.47in (46.1 x 21.3 x 12.1mm) 0.52oz (15g) 28410
Optima 7 2.20 x 0.89 x 0.43in (56.9 x 20.8 x 11.6mm) 0.60oz (17g) 28414
Optima 9 1.85 x 1.14 x 0.59in (47.7 x 29.1 x 15.5mm) 0.77oz (22g) 28425
Operating Voltage: 3.7~8.4V from a receiver battery or BEC circuit from an Electronic Speed Control
4.8~35v Using SPC Function
Current Drain: 30mA
Maxima Series 2.4GHz Receivers
Model Size Weight Stock Number
Maxima 6 1.29 x 0.81 x 0.42in (33 x 20.8 x 10.7mm) 0.22oz (6.4g) 27524
Maxima 9 1.45 x 0.98 x 0.57in (38 x 24.4 x 14.6mm) 0.28oz (8.1g) 27525
Operating Voltage: 3.7~8.4V from a receiver battery or BEC circuit from an Electronic Speed Control
Current Drain: 30mA
Minima Series 2.4GHz Receivers
Model Size Weight Stock Number
Minima 6 T 1.19 x 0.81 x 0.27in (30.4 x 20.8 x 7.1mm) 0.22oz (6.5g) 26610
Minima 6 E 1.24 x 0.81 x 0.42in (31.7 x 20.8 x 10.9mm) 0.28oz (8.1g) 26612
Minima 6 Lite 1.22 x 0.77 x 0.33in (31.2 x 19.5 x 8.5mm) 0.14oz (4g) 26614
Minima 6S 1.19 x 0.81 x 0.27in (30.4 x 20.8 x 7.1mm) 0.19oz (5.4g) 26615
Operating Voltage: 3.7~8.4V from a receiver battery or BEC circuit from an Electronic Speed Control
Current Drain: 30mA
Terms and Icons
Glossary of Terms
AFHSS 2.4GHz Signal: Hitec’s 2.4GHz R/C signal protocol. Adaptive Frequency Hopping Spread Spectrum.
Telemetry: Data signal from the model, transmitted to the transmitter.
Range Check: A ground check of the signal strength between the transmitter and receiver done before
ying.
Link (ID Setting): Link or “binding” a 2.4GHz receiver to its master transmitter.
HPP-22 PC Interface: PC interface accessory for storing model memories and updating rmware.
Icon Identication
MODEL: The model menu contains the model programming for the active model.
ACRO: Menu for xed wing, glow, gas and some electric models.
GLID: Menu for gliders and some electric models.
HELI: Menu for rotary wing aircraft.
AILE: Aileron for xed wing menus and the “roll” swash input for helis.
ELEV: Elevator for xed wing menus and the “pitch” swash input for helis.
RUDD: Rudder for xed wing menus and the “yaw”, or tail rotor input for helis.
INH: Inhibit is used to “turn o” a function.
ACT: Active, “turns on” a function.
NULL: “No switch” selected, the function or feature will be “on” all the time.
AUX: An “open” channel, without a control assigned to it.
J1: Right gimbal, up and down control.
J2: Right gimbal, side to side control
J3: Left gimbal, up and down control.
J4: Left gimbal side to side control.
T1: J1 control trim.
T2: J2 control trim.
T3: J3 control trim.
T4: J4 control trim.
LT: Non setted extra digital trim
RT: Non setted extra digital trim
RS: Right slider control.
LS: Left slider control.
