Holzmann TS 200 - Technic; Main Components; Specifications

TECHNIC
HOLZMANN Maschinen Austria www.holzmann-maschinen.at Seite 30
Tischkreissäge / table saw TS 200 / TS 250
11 TECHNIC
11.1 Main components
11.2 Specifications
TS 200 TS 250
Mains connection V/Hz 230 / 50 230 / 50
Engine power kW / (S6) 1,1 / 1,5 2,2 / 3,1
Speed U/min / min
-1
4700 4000
Saw blade Ø mm 200 254
Saw blade bore Ø mm 30 30
Table size mm 535 x 400 635 x 420
Maximum cutting width mm 750 750
Swivel range 90° - 45° 90° - 45°
Maximum cutting height mm 60 (90°) 40 (45°) 80 (90°) 65 (45°)
Diameter suction connection mm 50 / 25 50 / 25
Overall dimensions mm 1010 x 1580 x 940 1450 x 1000 x 1000
weight kg 75 kg 107 kg
Fig. 1
