HOLZMANN Maschinen Austria www.holzmann-maschinen.at Seite 35
Tischkreissäge / table saw TS 200 / TS 250
13 ASSEMBLY
13.1 Preparatory activities
13.1.1 Scope of delivery
After receipt of the delivery, if all parts are in order. Report any damage or missing items imme-
diately to your dealer or the shipping company. Visible damage must also be recorded without
delay in accordance with the provisions of the warranty on the delivery, otherwise the goods shall
be accepted as properly.
content:
1 saw body with switch, 1 saw blade hose, 1 90° mitre gauge, 1 Hose support, 1 Handwheel,
1 rip fence, 1 Slide rail, 1 Sliding carriage, 2 Extension table, 1 Floor stand, Support, sliding
carriage, 1 Set Tools, 1 Manual (see 13.3.2)
13.2 Workplace
Choose a suitable place for the machine. Observe the safety requirements of Chapter 12 and
the dimensions of the machine from Chapter 11.2.
The selected location must ensure as well as the possibility for connection to an extraction sys-
tem a suitable connection to the electrical grid.
Make sure that the floor can support the weight of the machine. The machine must be leveled
on all bases simultaneously.
You must also secure around a distance of at least 0.8 m around the machine. Before and be-
hind the machine must be provided the necessary distance for the supply of long workpieces.
13.2.1 Preparation of the surface
Eliminate the preservative, which is applied for corrosion protection of the parts without paint-
ing. This can be done with the usual solvents. Here no nitro solvent or similar means, and in no
case use water.
NOTE
The use of paint thinners, gasoline, corrosive chemicals or abrasive cleaners will result in
damage to the surface!
Therefore:
When cleaning, use only mild detergent
13.3 Assembly of parts removed for transport
The table saw is supplied pre-assembled. Broadening table, rip fence, miter gauge, riving knife
and saw blade and blade guard must be fitted.
