129
MAINTENANCE
POSITIONING
BAND
HARNESS
CLIP
WATER LEVEL
SENSOR 2P
CONNECTOR
POSITIONING
BAND
CLIP C
Connect the water level sensor 2P
connector. Install the harness to the
clip C and harness clip.
Align the positioning bands on the
harness with the end of the clip C
and harness clip as shown above.
Reinstall the water separator in the
reverse order of removal.
Squeeze and release the priming
bulb to fill the vapor separator, and
check for leaks.
If the buzzer sounds, water or
sediment accumulation is found to be
caused by excessive water or
sediment accumulated in the water
separator cup, inspect the fuel tank.
Clean the fuel tank if necessary.
9.
10.
11.
