Honda BF90D - Outboard Motor Installation

×
55 N·m (5.6 kgf·m , 41 lbf·ft)
Install the outboard motor
securely. Loosely mounted
outboard motor can result in
accidental loss of the motor
and damage and injury to the
equipment and personnel.
45
INSTALLATION
Outboard Motor Installation
Standard torque:
BOLT
(12 119 mm) (4)
STERN BRACKET
NUT (8)
WASHER (8)
WASHER (4)
ENGINE
HANGER (2)
Apply the silicone sealant
(Three Bond 1216 or
equivalent) to the outboard motor
mounting holes.
The standard torque is given just as a
guideline. Torque of the nut can be
different according to the material of
the boat. Consult with an authorized
Honda outboard motor deale r.
Before installing the outboard motor
on the boat, hang the outboard motor
with the hoist or equivalent devis e by
attaching the two engine hanger s to
the outboard.
Use the hoist which allowable load is
250 kg (551 lbs) or above.
Set the outboard motor on the boat
and secure with the bolts, washers,
and nuts.
1.
2.
