Honda BF90D - ACG Indicator;Buzzer

33
CONTROLS AND FEATURES (Common)
ACG Indicator/Buzzer(R1 type)
(R2, R3 types)
(H type)
(R type)
(RED)
BUZZER
BUZZER
(RED)
OVERHEAT
INDICATOR
(internal organs the buzzer)
OVERHEAT
INDICATOR
(indicator panel)
ACG INDICATOR
ACG INDICATOR
The ACG indicator turns on and the
buzzer sounds when the charging
system is faulty.
