Honda BF90D - Remote Control Installation (Equipped Type or Optional Equipment)

49
Remote Control Installation
(equipped type or optional
equipment)
Improperly installed steering
system, remote control box, and
remote control cable, or installing
those of the different types could
cause unpredictable accident.
Consult an authorized Honda
outboard motor dealer for proper
installation.
INSTALLATION
SIDE-MOUNT
TYPE CONTROL BOX
PANEL-MOUNT TYPE CONTROL
BOX AND SWITCH PANEL
TOP-MOUNT TYPE CONTROL BOX
AND SWITCH PANEL
(FOR DUAL MOTOR TYPE)
TOP-MOUNT TYPE CONTROL BOX
AND SWITCH PANEL
(FOR SINGLE MOTOR TYPE)
See an authorized Honda outboard
motor dealer for further information.
Select the most suitable control box
for your outboard motor considering
the installation position,
operationability, etc. of the control
box.
The control box is available in three
types as shown.
