Honda BF90D - Oil Pressure Indicator;Buzzer; Overheat Indicator;Buzzer

32
Oil Pressure Indicator/Buzzer Overheat Indicator/Buzzer(R1 type)
(R2, R3 types)
(H type)
(H type)
CONTROLS AND FEATURES (Common)
(GREEN)
BUZZER
BUZZER
OVERHEAT
INDICATOR
OIL PRESSURE
INDICATOR
(internal organs the buzzer)
(GREEN)
(GREEN)
(internal organs the buzzer)
OIL PRESSURE
INDICATOR
OIL PRESSURE
INDICATOR
(RED)
The oil pressure indicator turns off
and the buzzer sounds when the oil
level is low and/or the engine
lubrication system is faulty.
The engine speed slows down
gradually this time.
The overheat indicator turns on and
the buzzer sounds when the engine
cooling circuit is faulty. The engine
speed slows down this time.
