19
COMPONENT IDENTIFICATION
FUEL GAUGE
VENT KNOB
FUEL FILLER CAP
FUEL TANK
(equipped type)
FUEL TANK TUBE
ASSEMBLY
(equipped type)
FUEL LINE JOINT
(motor side)
FUEL LINE JOINT
(motor side)
FUEL TUBE ASSEMBLY
(equipped type)
FUEL LINE JOINT
(fuel tank side)
PRIMING BULB
PRIMING BULB
[Common]
