54
PRE-OPERATION CHECKS
Do not overfill the engine oil.
Check the engine oil after refilling.
Excessive engine oil as well as the
insufficient oil could cause damage
to the engine.
OIL FILLER CAP
R
R
i
i
b
b
o
o
f
f
t
t
h
h
e
e
A
A
C
C
G
G
c
c
o
o
v
v
e
e
r
r
When the engine oil is contaminated
or discolored, replace with the fresh
engine oil (see page for
replacement interval and procedure).
Install the engine cover and lock it
securely.
Oil filler cap removal (Unlock):
Turn the oil filler cap 90°
counterclockwise so the lug of the
cap sets horizontally.
Pull the cap to remove it.
Insert the oil filler cap into the oil
filler port with the lug being set
horizontally.
Turn the oil filler cap 90°
clockwise so the lug of the cap is
in line with the rib of the ACG
cover. (It should click.)
Oil filler cap installation (Lock):
4.
120
1)
2)
1)
2)
