64
(Using the fuel tank mounted on
the boat)
STARTING THE ENGINE
VENT KNOB
O
P
E
N
FUEL LINE CONNECTOR
To fuel tank
(FUEL TANK SIDE)
(FUEL TANK SIDE)
FUEL TUBE ASSEMBLY
(equipped type)
(motor side)
FUEL HOSE
(tank side)
HOSE CLAMP
(stainless steel)
BARB
Connect the fuel line to the tank.
Be sure the connector is securely
latched.
Open the fuel cap vent knob 2 to 3
turns.
Remove the hose plug from the
engine side fuel hose. Insert the
fuel line joint into the engine side
fuel hose and secure it with the
hose clamp. (The procedure is the
same as in the case of using a fuel
tank equipped type. Refer to the
previous page.)
Insert another fuel line joint up to
the barb of the joint in the fuel
tank side and secure it with the
hose clamp (stainless steel type).
Refer to the owner’s manual for
the boat.
3.2. 1.
2.
To Next Page
