Honeywell ESSER Fire Alarm Control Panel Compact User Manual

Fire Alarm Control Panel Compact
FB 798238.GB0 / 10.14 47
House alarm
House alarm
Text
TYPE
Trigger/switching
function
Monitoring
IN_1
Acoustics fault System input Acoustics fault
IN_2
Dialler fault Fault
IN_3
FPE fault System input FPE fault
IN_4
FPE triggered System input FPE triggered
OUT1
Common fire General Panel state fire
OUT2
Fault ATU General Panel state fault Calibrate
OUT3
Acoustic alarm device Acoustics Panel state fire EOL-O
OUT4
Strobe General Panel state fire EOL-O
REL_1
FPE FPE Panel state fire
REL_2
Common fire General Panel state fire
REL_3
Technical alarm General Panel state TAL
REL_4
Reset external detector General FACP reset
REL_5
Common fire General Panel state fire
RS485
Not in use
Underground car park
Underground car park
Text
TYPE
Trigger/switching
function
Monitoring
IN_1
Feedback input ATU System input ATU triggered
IN_2
Detector fault Fault
IN_3
FIE triggered System input SIES triggered
IN_4
FIE fault System input SIES fault
OUT1
Main detector ATU Panel state fire Calibrate
OUT2
Fault ATU General Panel state fault Calibrate
OUT3
Acoustic alarm device Acoustics Panel state fire EOL-O
OUT4
Strobe General Panel state fire EOL-O
REL_1
FIE (preflood/extinguish) FIE Panel state fire
REL_2
FSKB fire General Panel state fire
REL_3
FSKB ATU triggered General
Panel state ATU
triggered
REL_4
Reset external detector General FACP reset
REL_5
RS485
FIP/FOP
