Table 3. Items appearing in the "Plant Components" listbox
Application
AH03 HT02 HE01
items
Sensors Sensors Sensors
AHU_Strategy Htg_Strategy Heat Exchg.1
Dam
p
ers Boiler1 S
y
stem
Ener
gy
Recover
y
Boiler2 Heatin
g
Circ.1
Filters Boiler3 Heat Exch
g
.2
Heating Boiler4 Heating Circ.2
Coolin
g
S
y
stem Dom. Hot Water1
Humidit
y
Heatin
g
Circ.1 Dom. Hot Water2
Fans Heatin
g
Circ.2 Pulse meters
Heating Circ. Heating Circ.3
Boiler Dom. Hot Water LON meter
Zone1 Heat meter
A
larms
Zone2 Alarms Time Programs
Zone3 Time Programs LON
Zone4 LON Ht
g
Strate
gy
A
larms
Time Programs
LON
Data-Points
Selecting an individual group of data-points (e.g. "Sensors") will cause a listbox
(including a scrollbar at the right-hand margin) with a corresponding heading to
appear (see Fig. 9).
Fig. 9. Listbox of data-points belonging to a plant component
Depending upon your given application and configuration data, this listbox will
contain a varying number of items (i.e. data-points) meaning that you may have to
scroll downwards through several screens in order to display all of the items.
